nitro group adBlueOBD2 for MB Atego Euro 6 Remove adBlueOBD

Behind fuses in the middle is a plug- as in the price (not right like in manual-correct is middle)
Connnection colors-White with Blue (Truck side) with White (Truck side)

Red wire from emulator connection with any(+)after ignition

Black i GND

Next step is remove Fuse

F23 Thats all

You must locate the ACm Module and remove the socket.
The cable should be installed as shown in the picture below.
adBlueOBD2 White cable(CAN H) —–Atego vehicle socket 10 pin(CAN H)
adBlueOBD2 Brown cable (CAN L) —– Atego vehicle socket 20 pin (CAN L)
adBlueOBD2 Red (+) —–Atego vehicle Positive(+)Cable
adBlueOBD2 Black(-) —–Atego vehicle GND (-)

After installation, you must remove errors with fault detecting device.
The DTC fault code eraser can also be used to erase the fault in your Atego vehicle

You will not mount the socket back into the ACM module Isolate the Atego ACh nodule without damage.
